How to Connect Wireless Microphone Receiver to Mixer? Simple Guide

Wireless microphones use a receiver that captures the high-frequency signal transmitted from the microphone. To connect a wireless microphone receiver to the Mixer or sound system, you will need the correct cable to connect the receiver to and a soundboard.

Step-by-step guide to Connect a Wireless Microphone Receiver to a Mixer

Step 1. Connect power to the receiver. Look at the back of the wireless microphone’s receiver. It has an XLR, three prongs, or a 1/4 inch, one-hole output jack. Use an XLR or 1/4-inch cable for the output of the wireless microphone receiver.

Step 2. Connect the other end of the receiver cable to an unused track on your Mixer or soundboard. The inputs for each track are on the back of the Mixer.

Step 3. Make sure the microphone and receiver are set to the same frequency. This is to allow the receiver to receive transmissions from the wireless microphone.

Step 4. Set the track’s fader to which you have connected the wireless receiver to zero. Have someone speak into the microphone while you turn the Mixer’s gain knob. The gain knob brings the signal into the track. This should allow you to hear the speaker’s voice gradually increasing. Make sure the Master Fader is set to 0.

Note:

  1. Make sure your wireless microphone has new batteries.
  2. If you hear interference, change the frequency of the wireless microphone and receiver.
  3. When you hear feedback, move the microphone away from the speaker if possible.

Here is 2024’s guide on connecting a Wireless Microphone for Vokeme readers.

How to connect a wireless microphone to a speaker?

1. The microphone must have AA batteries and a rechargeable wireless microphone to ensure power supply.

2. Connect the audio output interface of the inbox and the audio input interface of the speaker with an audio cable. And connect the inbox power supply.

3. Turn on your phone’s Bluetooth to search for a pairing. When connected, the light on the inbox will flash and stay on.

4. Turn on the microphone switch; the whole program is finished, and you can sing as you like. The effective range of wireless microphones is tens of meters beyond the limits of wired.

How to connect a Wireless Microphone Receiver to an Amplifier?

1. Connect the receiver to a power supply, attach the included two-wave antenna, and turn on the receiver’s power switch.

2. Insert the battery into the microphone and turn it on.

3. Check the RF lighting or frequency conversion function to ensure the duo is connected. Alternatively, check the frequency on the receiver to ensure it matches the microphone’s current frequency.

4. Connect the amplifier to a power source, turn it on, and check that it is enabled by looking for OK on the allow light.

5. Connect one end of the XLR cable to the receiver and the other end to the PA system/amplifier.

6. Adjust the amp’s volume to your liking, and you’re all set.

How to connect a wireless microphone to the karaoke system?

1. Set up the microphone and output the sound from the microphone to the home speaker.

2. Output music from karaoke to home speakers. This could be the same set of speakers used by the microphone or another set of speakers.

3. Output the video from the karaoke to the TV.

How do you connect a wireless microphone to Smartphones?

If your microphone has built-in Bluetooth, here’s how to connect it with your iPhone and Android phone.

1. Turn on the Bluetooth microphone and enable Bluetooth on your phone.

2. Click the Open Bluetooth menu on your phone while ensuring the visibility status of your phone’s Bluetooth is “On.”

3. Make sure your microphone and phone are both within range.

4. Check the microphone icon in the phone’s Bluetooth list and connect.

Remember:

The same principle applies if you plan to use an XLR Bluetooth transmitter. The only difference is that it pairs the phone’s Bluetooth with the XLR-Bluetooth transmitter’s Bluetooth connected to the microphone.

Can I use my wireless microphone with any receiver?

Wireless microphones will likely come with their receivers and may not respond to connections with other receivers. However, you may need to check the user manual to confirm. It depends on the manufacturer and microphone model.

What do you need for a wireless microphone system?

People in the audio industry often take specific facts for granted. We need a PA system to connect a microphone and speakers to get sound from an amplifier, and we know that different sound systems are suitable for other applications.

Creating a great-sounding (or simply functional) microphone system without guidance can be daunting for audio beginners, who can include everyone from meeting planners to teachers. Here are three things you will need to buy:

  • Microphone
  • Transmitter
  • Receiver

A microphone is simply the component through which the user speaks (or sings). It converts sound waves into electrical impulses and amplifies them so the listener can hear them. In a wireless microphone, electrical signals are passed to a transmitter that converts the signal into radio waves. (You can also alter the signal to infrared, but for this article, we will use the radio).

The transmitter is usually built into a handheld microphone body (a capsule). For hands-free microphones such as lavaliers and headsets, the transmitter is typically a pack worn by the user on a belt.

The transmitter broadcasts to the receiver, which converts the radio waves back into electrical signals that can be passed to the sound system. Perhaps the excellent system is the fourth component, but I’ll skip it here as it’s covered elsewhere. Without these components, your wireless microphone will not work.

Wired Vs Wireless Microphones?

A question asked by Vokeme readers is what to use a wired or wireless microphone. The wireless microphone system is one of the most sought-after equipment in a mobile DJ’s arsenal. The reason is apparent. Wireless technology has advanced so much that it is almost impossible to tell the difference between wired and wireless audio quality.

What is the difference between wired and wireless?

Wired microphones have a cord that can be plugged into a sound system or PA system, while wireless microphones use a transmitter to send signals wirelessly.

Wireless microphones are more expensive than wired ones because they require a replaceable battery. But it is also more convenient in some ways because you don’t have to worry about tripping the cord on stage! There are many benefits of using a wireless microphone, as mentioned below.

What are the benefits of a wireless microphone?

  1. Easy to use.
  2. Remove the cord and use a wireless microphone.
  3. Do it without the fear of tripping over the wire.
  4. You can move freely on stage or the dance floor.
  5. Speak more confidently in front of large audiences.
  6. Eliminate the hassle of unravelling the code every time you want to perform.
  7. Perform in front of large audiences without worrying about tangled cords.

To help Vokeme visitors, we have complained about the top professional wireless Microphone systems that are best to buy in 2024.

List of Best Wireless Microphone Systems for Professionals 2024

1. Shure SLXD24-B58 Wireless System

The Shure SLXD wireless vocal system is the perfect tool for replacing cords with a wireless connection. From auditoriums and chapels to large and small stages, the SLXD can easily connect to virtually any environment.

With our versatile suite of wireless microphone system configurations in single half-rack or dual full-rack receivers and handheld or bodypack transmitters, you have multiple options for the perfect vocal and lavalier microphone system in various settings.

Shure UHF antenna distribution simplifies antenna connections without long RF cables, and remote antennas can be easily adjusted as needed.

With up to 8 hours on 2 AA batteries. Upgrade to the optional Shure SB903 Li-Ion Rechargeable Battery to monitor battery charge in hours and minutes and monitor battery life and health statistics.

Shure SLXD24-B58 Wireless System

Pros

  • Select a radio frequency band
  • Digital radio technology
  • Crystal-clear 24-bit/48 kHz digital audio
  • Up to 8 hours of battery life

Cons

  • A bit expensive


2. Audio Technica 10 ATW-1102

The Audio-Technica 10 ATW-1102 is a fantastic microphone in the best wireless microphone system on the market. The wireless system runs in the 2.4 GHz frequency range, ultimately blocking TV interference.

Moreover, this wireless system has its own automated internal frequency selection tool to detect interference and maintain a safe frequency channel.

We have been using this device for public performances; it can get up and running quickly. The microphone has been tested up to 4, and you can use up to 8 channels together without any problems.

The only downside I can mention is the battery life. Several tests have shown that the average battery life is around 4 hours.

This is sufficient for most people but should be considered for performance and warm-up. Regarding the sound performance, it’s well worth it.

Audio Technica 10 ATW-1102

Pros

  • Automated internal frequency selection tool
  • 2.4 GHz frequency range
  • Ultimately blocking TV interference
  • Use up to 8 channels together

Cons

  • Average battery life

3. Shure ULXD2/SM58

No one can compete with the Shure ULXD2 for a high-quality digital handheld professional wireless microphone system. The system features a cardioid dynamic capsule that rejects feedback and significantly reduces background noise, making it an ideal choice for presenters, vocalists, or anyone looking for high-quality vocals.

Additionally, the unit is designed with a bright midrange and bass roll-off to ensure you can sing with the highest clarity and warmth.

If you’re looking for a reliable digital system that delivers professional sound in studio environments and performance settings.

Shure ULXD2/SM58

Pros

  • Excellent for studio environments and live performance
  • Cardioid dynamic capsule system
  • Significantly reduces background noise
  • AA batteries have up to 9 hours of backup

Cons: Too simple.

Conclusion

Wireless microphones help to avoid tangling in webs or cables. This state-of-the-art microphone is a lifesaver. But at the same time come their difficulties. This is especially true if you want to secure a tight wireless connection that doesn’t end badly. So far, this article has shown you how to connect a wireless microphone.
